Waterproof Tread Screw M12 Connector For Front Panel Mounting In 60V Voltage Range

Name: Waterproof Tread Screw M12 Connector For Front Panel Mounting In 60V Voltage Range
Brand: DREAM-START
Price: 0.54 USD

Wholesale Waterproof Tread Screw M12 Connector For Front Panel Mounting In 60V Voltage Range from china suppliers

Place of Origin : Guangdong, China

Brand Name : DREAM-START

Model Number : DR-D18

Supply Ability : 100000 Piece/Pieces per Month M12 connector

MOQ : 20 pieces

Price : $0.54 - $1/pieces

Certification : TUV

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Delivery Time : Within 24 hours

Packaging Details : Decide the carton size according to the quantity

Application : Electric Bike

Gender : Male/Female

Keywords : waterproof connector

Contact Now

1. M12 metal nut type docking assembly, more exquisite and more durable;

2. Integrating current and signal transmission in one of the multi-functional comprehensive waterproof plug;
3. Metal nut locking makes a better tensile performance and better waterproof performance;
4. The male and female pins of gold-plated ensure the conducting performance's stability, safe and reliable;
5. Mainly used for upscale lighting accessories lines and other upscale products.

Pins Number	Rated Current	Rated Voltage	Contact Resistance	Contact Resistance	IP-Code	Cable Specifications	Cable Range
2	8A	110V AC	10mΩ	200MΩ	IP67	≤1.0mm2	0-7.5mm
3	8A	110V AC	10mΩ	200MΩ	IP67	≤1.0mm2	0-7.5mm
4	5A	80V AC	10mΩ	200MΩ	IP67	≤0.75mm2	0-7.5mm
5	5A	80V AC	10mΩ	200MΩ	IP67	≤0.5mm2	0-7.5mm
6	4A	60V AC	10mΩ	200MΩ	IP67	≤0.5mm2	0-7.5mm

Waterproof Tread Screw M12 Connector For Front Panel Mounting In 60V Voltage Range
